Fire Magic Deluxe 11-Piece 36-Inch Natural Gas Outdoor Kitchen Package
Product Info Guide
Recommended AccessoriesBack to Top
- Grill features unique 5 Ways to Cook system allowing you to grill, sear, smoke, rotis and even charcoal grill
- Grill, power burner, and double side burner feature blue LED back-lit control knobs
- Keep ingredients fresh and beverages cold with the compact refrigerator, ice maker and refreshment center
- Fire Magic products are proudly made in the USA and have been since 1937
- Package Includes: Echelon Diamond 36-inch built-in natural gas grills, power burner, double side burner, 5.1 cu. ft. outdoor rated comapct refrigerator, 63 lb outdoor rated ice maker, refreshment center, 14-inch soft closing triple access drawer, 30-inch
This Fire Magic Outdoor Kitchen Package has everything you need for the luxury outdoor kitchen of your dreams. Included is an Echelon Diamond 36-inch natural gas grill featuring 304 stainless steel construction for lasting quality, and modern styling with a sleek, contoured control panel. It comes with a spring-assisted, double-walled tear-drop hood, a removable warming rack, a 12V electric hot surface ignition with flash tube back-up and a 12 inch deep firebox for complete convection cooking. The one main infrared and two main cast stainless steel E burners produce a total of 99,000 BTUs on the grilling surface, and the Diamond Sear cooking grids provide an ample 792 square inches of grilling area. This grill also features a 13,000 BTU stainless steel Quantum rotisserie burner with rotisserie kit, which heats up quicker than other rotisserie burners and is designed to direct heat only to the food and not the rest of the grill. The grill also comes with a stainless steel charcoal/smoker basket for adding wood-fired flavor to your food. The heat zone separators allow you to cook at different temperatures across the grilling surface, while the integrated premium digital thermometer lets you monitor the temperature of each cooking zone. The thermometer also includes a meat probe, timer and alarms that can set for cooking zone temperature and food temperature. The angled 12V halogen oven lights and back-lit knobs make cooking at night simple and fun. For addtional cooking space, a power burner and a double side burner are included in this package. The power burner features a cast brass burner producing up to 60,000 BTUs and a porcelain cast grid to easily accommodate large woks and stock pots. The double side burner features two 15,000 BTU, independently controlled solid brass burners and a stainless steel cooking grate. Both the power burner and the double side burner come with stainless steel lids to protect from the outdoor elemetns when they are not in use. For keeping cold beverages and fresh ingredients on hand, a 5.1 cubic foot outdoor rate refrigerator, refreshment center, and an ice maker have been included in this package. The ice maker produces up to 63 pounds of ice in 24 hours and can store up 27 pounds at a time. Plenty of storage space is provided with a 10 1/2 gallon roll-out trash bin, 14-inch soft closing triple access drawer, 30-inch soft closing double access door, and a 36-inch soft closing access door with platter storage and soft closing double drawers. A 60-inch, 1,200 CFM outdoor vent hood come with this package to ensure smoke does not linger in your outdoor kitchen.
Legal disclaimers and warnings
Product packaging, owners’ manuals, installation instructions, and/or operating instructions may include more information than what is shown on our website. The content on our site is intended to be used for reference purposes only. Please fully read all included manuals and documentation before installing or using this product. WARNING for California residents: this product may contain chemical(s) known to the state of California to cause birth defects, cancer, or other reproductive harm.
- Model Number
- E790i-4L1N + 19-4B2N-0 + 53825-T + 32814 + 53803SC + 3597 + 53816SC + 53930SC + 3596A + 60-VH-6 + 3589-DR
|Gas Grill Class||Luxury|
|Fuel Type||Natural Gas|
|Exterior Material||Stainless Steel|
|Exterior Stainless Grade||304 Stainless Steel|
|Cooking Grate Material||Stainless Steel|
|Cooking Grid Dimensions||36 X 22"|
|Main Grilling Area||790"|
|Secondary Grilling Area||288"|
|Total Grilling Area||1080"|
|Number Of Doors||3|
|Number Of Drawers||5|
|Grill Lights||Internal / External|
|Includes Trash Bin||Yes|
|Spring Assisted Hood||Yes|
|Includes Paper Towel Holder||Yes|
|Includes Tank Holder||No|
|Extra Features||Most Powerful Built-In Gas Grill Award Winner; Trapezoid Cooking Grates; Includes Large Capacity Charcoal/Smoker Box; Warming Rack / Rotisserie Rod Storage; Blue Backlit Knob Illumination|
|Made In USA||Yes|
|Cut Out Width||37"|
|Cut Out Depth||23 1/2"|
|Cut Out Height||12"|
- Fire Magic E790i Grill Quick Start Guide
- Fire Magic E790i Grill Manual
- Fire Magic E790i Grill CAD Drawing
- Fire Magic Grill Multi-User Warranty
- Fire Magic 19-4B Power Burner Manual
- Fire Magic 19-4B Power Burner CAD Drawing
- Fire Magic 32814 Side Burner Manual
- Fire Magic 32814 Side Burner CAD Drawing
- Fire Magic 3589 Refrigerator Manual
- Fire Magic 3597 Ice Maker Manual
- Fire Magic Vent Hood Manual
- Fire Magic Trash Bin Manual
- Fire Magic Care of Stainless Steel Guide
- Fire Magic Product Specifications
WarrantyBack to Top
Fire Magic provides a lifetime warranty for cast stainless burners, stainless cooking grids and housings. Stainless flame tamers are warranted for five years, all other components (except ignition and electronic parts) for three years, ignition systems (except batteries) and electronic components (including lights & thermometers) for one year. A limited one year labor warranty covers repairs up to $95. In a multi-user setting (excluding commercial use) this grill is warranted to be free from defects in material and workmanship for the stainless grill housing, burners, cooking grates, brass valves, inner lines and manifold assemblies for five years, all other components (except batteries) are warranted for one year. Fire Magic outdoor components such as vent hoods, trash bins, doors, drawers, refreshment centers and side burners (except ignition systems and electrical parts, which are covered for one year) are warranted against defects for three years. For refrigerators, Fire Magic offers a one year parts warranty on mechanical and electrical parts. The components of the sealed refrigeration system, such as the compressor, condenser and evaporator are covered for a period of five years from the date of purchase. The Fire Magic ice maker is warranted for one year from the date of purchase.
